The ULTRON 10-inch touchscreen computer (ULT101, Part#N100) is a compact, cost-effective touchscreen tablet powered by the energy-efficient Intel® Celeron N100 processor, ideal for space-constrained environments like retail kiosks, customer feedback kiosks, and self-order kiosks. Its 1280x800 resolution display with 500cd/m² brightness (425cd/m² with touchscreen) and G+G 10-point capacitive touch with optically bonded glass delivers responsive, clear visuals. Supporting Windows 11 and Linux, this commercial touchscreen is perfect for point-of-sale kiosks and interactive signage, offering robust connectivity and a lightweight design for seamless integration into automated kiosk systems.

How to Buy

Interactive

Touchscreen Features.

Compact Display

10-inch, 1280x800 resolution with 425cd/m² brightness and 800:1 contrast ratio for vibrant visuals.

Peripheral Options

Supports barcode scanners (Newland, Zebra) and RFID readers for retail kiosk functionality.

Bulletproof Build

Metal frame crushes chaos—drop-proof and unstoppable.

Lightning Touch

Bonded glass for instant swipes and ultra-slim sleekness.

One-Plug Wonder

No cables, just plug and power up—pure pro simplicity!

Support for Linux

Fully Compatible with Windows 11 loT ENTERPRISE

Specifications.

Panel Info

Size	10.1"
Resolution	1280 x 800
Panel Brightness	500cd/m²
Brightness	425cd/m² with touch Screen
Contrast	800:1
Aspect Ratio	16:10
Active Display Area	216.96x135.6 mm
Viewing Angle	85°/85°/85°/85°
Response time	10ms

Touch Data

Touch Tech	G+G 10 point cap touch
Hardness Of Surface	＞6H
Touch method	Finger touch, Capacitive stylus
Transparency	≥86%
Touch Glass Thickness	2mm (Not including Sensor thickness)
Bonded Panel	Not supported Bonded Panel

Hardware & OS

CPU	N100
Base Frequency	N/C
CPU Turbo Boost	3.4GHz
Core	4
Thread	4
CPU Cache	6MB
BIOS	AMI UEFI BIOS
RAM	8GB , Single Channel SO-DIMM DDR4 (Max 16GB)
ROM	256GB, M.2 for NVME 2280 SSD
Additional Storage	1 x SATA 3.0 slot, 1 x M.2 for NVMe 2280 SSD
OS	Win 11 64 bit, Linux 64 bit
GPU	Integrated Intel® UHD Graphics

Connectivity

Speaker	2x2W
Bluetooth	BT 5.3
WIFI	IEEE 802.11a/b/g/n/ac/ax , Bluetooth 5.3 (Dual antenna)
Display Ports	1 x VGA, 1 x HDMI 1.4
Connectors	1 x RJ45
Wake on LAN	Yes
LAN	1 x (10/100/1000 Mbps)
USB Ports	3 x USB 3.0, 1 x USB 2.0, 6 x USB 2.0 headers
Audio	Line-out x 1, Mic-in x 1
COM Ports	2 x RS232 + 1 x RS485 or RS422
GPIO	4 x GPIO
4G	Not supported on N100 due to structural limitations

General

Color	Matte Black
Housing	Metal Housing
Camera	2MP
Operating Environment	Working Temperature: 0-45 degree celsius
Included in Box	Ultron Tablet, Power Adapter, Power Cable
Language	Multi Language
Metal Button	1 × Power Button
Hardware Monitor	CPU temperature Sensor, Voltage Sensor, Watch dog, Plug and Start

Power Management

Power supply unit	External
Power supply	DC 12V 5A
Power usage	TBD

Sustainability

Regulations	FCC, CE, UKCA , RoHS support
REACH SVHC	REACH does not contain SVHC above 0.1%: Lead

Mounting & Dimensions

VESA	75 x 75
Dimensions ( WxDxH)	TBD
Weight	TBD
Box size / each pc(LxWXH)	TBD
Master Box size ( LXWXH)	TBD
Master Box Weight	TBD
Pieces/ Carton	TBD

Amazing accessories
to complete your perfect kiosk touchscreen computers.

The Touchscreen Computers offers a wide assortment of optional peripherals such as magnetic card swipe, RFID/NFC readers and barcodes that enables flexibility for rigorous use in continuous public use for fitness consoles, system terminals, retail e-catalog, employee access control, corporate check in, restaurant self ordering, hotel check in, etc.
